– JNU792C-7100 _Core i3 Processor
– JNU792V-3865 UTX _Celeron Processor
– COM series: HBFCU792C-7100-B / HBFCU792CW-7100-B
– TPM2.0 series: HBFCU792C-7100-T / HBFCU792CW-7100-T
– VGA series: HBFCU792V-3865-B / HBFCU792VW-3865-B
|BIOS||– AMI 16MB SMT Flash ROM|
– Intel® Skylake/Kabylake U-series Processor (MAX : TDP 15W)
Notes : When the system runs, CPU will automatically adjust its working clock frequency according to changing workload.
|Memory||– 2 * 260-pin Dual-channel DDR4 2133MHz SODIMM Up to 32 GB|
– 1 * 2.5” SATA3 6Gb/s internal drive bay
– 1 * Full-size mSATA/mini-PCI Express shared slot
– 1 * Intel i211AT Gigabit LAN, 1 * Intel i219LM Gigabit LAN
– 1 * Half-size mini-PCIE slot (for WIFI model installed)
|Rear Panel I/O||
– 4 * USB 3.0 ports / HBFCU792C-XXXX-B only
– 2 * USB 3.0 ports , 2 * USB 2.0 / HBFCU792V-XXXX-B only
– 1 * HDMI 1.4 (max. 4096 x 2304@24Hz resolution)
– 1 * DP (max. 4096 x 2304@60Hz resolution) / HBFCU792C-XXXX-B only
– 2 * RJ45
– 1 * Line-in, 1 * Mic+Line out (Realtek ALC662VD)
– 2 * Antenna holes (WiFi only)
– 1 * DC-In jack
|Front Panel I/O||
– 1 * Power button
– 1 * Power LED , 1 * HDD LED
– 2 * USB 2.0 , 2 * USB 3.0
– 1 * COM (RS232/422/485) / HBFCU792C(W)-XXXX-B only
– 1 * VGA / HBFCU792V(W)-XXXX-B only
– FSP AC TO DC Adapter / DC12V_3.3A_40W
– AC 90~240V input
|Compliance||– CE, FCC, LVDS, RoHS, ErP Ready|
– Operating Temperature: 0 ~ 50° C
– Storage Temperature: -10 ~ 70° C
|Dimensions||– 144 (W) x 116.9 (D) x 65 (H) mm|
– Net Weight: 1.8KG
– Gross Weight: 2.8KG
– Color Box dimension: 250 (W) * 118 (D) * 295 (H) mm
|OS Support||– 32/64 bit versions of Windows 7, Windows 8.1, Windows 10, Linux|
|Warranty||– 2 Year limited warranty|
|Data sheet||Download (PDF)|
|Data sheet||Print view|
|Jetway Catalog (Rackmount)||Download (PDF)|
|Jetway Catalog (Barebones)||Download (PDF)|
